KEY PERFORMANCE FACTORS
Lighter weight
New EnergyPak 400 battery is designed to be ultra slim. You get all the power but in a smaller package that’s cleanly integrated with the composite frameset.
Advanced cockpit control
RideControl Ergo 3 remote attaches to the all-new composite Giant Contact SLR integrated handlebar. The control can be mounted to either side of the handlebar so you can customise your controls for a clean, uncluttered cockpit.
More power
New SyncDrive Pro motor, co-developed with Yamaha, puts out a powerful 85Nm of torque and weighs just 2.7kg. The result is quicker acceleration and climbing capabilities on technical trails.
SPECIFICATIONS
- MotorGiant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology"
- BatteryGiant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible
- ChargerGiant EnergyPak 4A smart charger, 60% in 1:45
- ControllerGiant RideControl Ergo3, grip integrated remote
- DisplayGiant RideControl GO, frame integrated LED console Optional wireless ANT+ display
- SizesS, M, L, XL
- ColoursMirage/Black
- FrameAdvanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
- ForkFox 36 Factory Live Valve, 150mm travel, 44mm offset, Boost 110x15QR, electronic adaptive suspension, e-bike integrated
- ShockFox Float X Factory, EVOL, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30%
- HandlebarGiant Contact SLR Trail Integrated, Advanced Composite, 5-position adjustable, 800mm, meets DH test standard
- StemGiant Contact SLR Trail Integrated, Advanced Composite, 5-position adjustable, 40/45/50mm Reach, +3°/0°/-3° Adjust System
- SeatpostFox Transfer Factory (S:125, M:175, L:150, XL:200)
- SaddleGiant Romero SL, Neutral
- PedalsPEDALS NOT SUPPLIED
- ShiftersSRAM AXS Rocker Paddle, wireless electronic shifting
- Front DerailleurMRP HD2 co-moulded chain guide
- Rear DerailleurSRAM XO1 Eagle AXS
- BrakesSRAM Code RSC, 4-piston, hydraulic disc,220mm[F] / 200mm[R]
- Brake LeversSRAM Code RSC
- CassetteSRAM XG-1299, 10-52T, 12-speed
- ChainSRAM XX1 Eagle Powerlink
- CranksetPraxis Performance Carbon e-crank arms, (S:160,M/L:165, XL:170) SRAM X-SYNC Eagle 36T chain ring
- Bottom Bracketn/a
- RimsZipp 3MOTO 29" [F] /27.5" [R], Carbon, with Quarq Tyrewiz
- HubsZipp 3MOTO ZM2
- SpokesZipp 3MOTO
- TyresMaxxis Dissector 29X2.40"" Foldable, TLR, EXO [F] Maxxis Rekon 27.5x2.4"" Foldable, TLR, EXO+ [R]
- ExtrasTubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- S
- 163 cm
174 cm
- M
- 171 cm 182 cm
- L
- 176 cm 186 cm
- XL
- 183 cm 193 cm
| S | M | L | XL | ||
| LOW | HIGH | LOW | HIGH | LOW | HIGH | LOW | HIGH | ||
| A | SEAT TUBE LENGTH (mm) | 400 | 425 | 450 | 475 |
| B | SEAT TUBE ANGLE | 77.2° | 78.0° | 76.0° | 76.7° | 76.0° | 76.7° | 76.0° | 76.7° |
| C | TOP TUBE LENGTH (mm) | 577 | 575 | 607 | 605 | 636 | 634 | 665 | 663 |
| D | HEAD TUBE LENGTH (mm) | 95 | 100 | 115 | 130 |
| E | HEAD TUBE ANGLE | 65.7° | 66.5° | 65.8° | 66.5° | 65.8° | 66.5° | 65.8° | 66.5° |
| F | FORK RAKE (mm) | 44 | 44 | 44 | 44 |
| G | TRAIL (mm) | 113.1 | 108.0 | 113.1 | 108.0 | 113.1 | 108.0 | 113.1 | 108.0 |
| H | WHEELBASE (mm) | 1194 | 1195 | 1215 | 1212 | 1244 | 1244 | 1275 | 1275 |
| I | CHAIN STAY LENGTH (mm) | 447 | 447 | 447 | 447 | 447 | 447 | 447 | 447 |
| J | BOTTOM BRACKET DROP (mm) | 10 | 10 | 10 | 10 |
| K | STACK (mm) | 607 | 601 | 611 | 605 | 625 | 619 | 639 | 633 |
| L | REACH (mm) | 439 | 447 | 457 | 462 | 480 | 487 | 505 | 513 |
| M | STAND OVER HEIGHT (mm) | 726 | 735 | 733 | 742 | 732 | 741 | 741 | 750 |
| N | HANDLEBAR WIDTH (mm) | 780 | 780 | 780 | 780 |
| O | STEM LENGTH (mm) | 40 | 40 | 50 | 50 |
| P | CRANK LENGTH (mm) | 160 | 165 | 165 | 170 |
| Q | WHEEL SIZE | R27.5" / F | R27.5" / F | R27.5" / F | R27.5" / F |
