BUILT FOR ADVENTURE, THE EXPLORE E+ TURNS COMMUTES AND ESCAPES INTO OPEN HORIZONS. WITH VERSATILE DESIGN AND SEAMLESS INTEGRATION, IT DELIVERS SMOOTH SUPPORT, CONFIDENCE, AND FREEDOM TO RIDE FARTHER—WHEREVER THE JOURNEY LEADS.
KEY PERFORMANCE FACTORS
CONFIDENCE & COMFORT
POWER THAT LASTS
PROTECTION YOU TRUST
HIGHLIGHTS
The Explore E+ is built to expand what’s possible on every ride. Its modern frame introduces an elevated chainstay for quiet, low-maintenance drivetrains, while the one-piece rear carrier integrates lighting and radar-ready safety. At its core is the newly evolved E+ System: a 36-volt SyncDrive Pro 2 motor (Explore E+ 0 & 1 only) delivering 85Nm of torque and up to 400% support, paired with the long-lasting EnergyPak battery (Explore E+ 0 & 1 800Wh, Explore E+ 2 & 3 625Wh, Explore E+ 4 500Wh) and intelligent Smart Assist. A refined cockpit combines the RideDash Evo 2 display, RideControl Ergo 4 dual-sided remote, and RideControl Go 2 button for intuitive interaction, while E-Shift with belt drive* keeps every pedal stroke smooth. From daily commutes to cross-country escapes, the Explore E+ turns every route into an open horizon.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
- S
- 162 cm
172 cm
- M
- 169 cm 179 cm
- L
- 176 cm 186 cm
- XL
- 183 cm 193 cm
- XXL
- 190 cm 200 cm
| S | M | L | XL | XXL | ||
| A | SEAT TUBE LENGTH (mm) | 435 | 485 | 535 | 585 | 610 |
| B | SEAT TUBE ANGLE | 74.0° | 73.0° | 73.0° | 73.0° | 73.0° |
| C | TOP TUBE LENGTH (mm) | 570 | 590 | 610 | 630 | 650 |
| D | HEAD TUBE LENGTH (mm) | 130 | 140 | 155 | 170 | 185 |
| E | HEAD TUBE ANGLE | 69.5° | 69.5° | 69.5° | 69.5° | 69.5° |
| F | FORK RAKE (mm) | 42 | 42 | 42 | 42 | 42 |
| H | WHEELBASE (mm) | 1112 | 1121 | 1142 | 1163 | 1163 |
| I | CHAIN STAY LENGTH (mm) | 455 | 455 | 455 | 455 | 455 |
| J | BOTTOM BRACKET DROP (mm) | 60 | 60 | 60 | 60 | 60 |
| K | STACK (mm) | 610 | 619 | 633 | 648 | 648 |
| L | REACH (mm) | 395 | 400 | 416 | 432 | 432 |
| M | STAND OVER HEIGHT (mm) | 745 | 775 | 808 | 844 | 844 |
| N | HANDLEBAR WIDTH (mm) | 690 | 690 | 690 | 690 | 690 |
| O | STEM LENGTH (mm) | 60 | 70 | 80 | 90 | 90 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C | 700C |
SPECIFICATIONS
- MotorGiant SyncDrive Sport2, 75Nm PedalPlus 6-sensor technology
- BatteryGiant EnergyPak Smart 500Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production
- ChargerGiant EnergyPak 4A smart charger compact, 60% charge in 2:30h
- ControllerGiant RideControl Dash 2, Smart Assist automatic mode, 5 support levels
- DisplayGiant RideControl Dash 2 high-angle visibility, full color LCD display
- SizesM, L, XL
- ColoursStealth Chome
- FrameGen 3 ALUXX aluminum, Overdrive 1.8" - 1.5" head tube, integrated battery, integrated KSA40 kickstand mount
- ForkSR Suntour XCM34 Boost DS 100mm travel 15AH4-110 axle
- Shockn/a
- HandlebarGiant Connect Riser 31.8x690mm
- StemGiant Contour integrated 16⁰ (S/M:80mm L/XL/XXL 100mm)
- SeatpostGiant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
- SaddleSelle Royal Vivo Ergo Moderate Unisex
- PedalsAnti-slip Platform Pedal
- ShiftersShimano Cues
- Rear DerailleurShimano Cues 9-speed
- BrakesTektro HD-M280, hydraulic disc, 180mm
- Brake LeversTektro HD-M280
- CassetteShimano Cues, 11-36T, 9-speed
- ChainShimano Linkglide CN-LG500
- CranksetForged alloy spider w/chainguard BCD 104, steel narrow/wide chainring 46T
- RimsGiant GX03V, 622x21 Aluminium
- HubsGiant eTracker Boost 6-bolt disc 15x110mm [F] 12x148mm [R]
- SpokesStainless steel, e-bike optimized
- TyresCrosscut Gravel 2, 700x57c, Wire Bead, Tubeless Ready,w/ Reflection Strip
- ExtrasHMI 2.0 including E locking and Apple Find My
